DLP-600 intelligent water bag/stacking bucket three-dimensional liner bag making machine

DLP-600 water bag/stacking bucket three-dimensional liner bag intelligent bag making machine is a good packaging device, specially designed for making water luggage and stacked barrel three-dimensional lining baggage. The system adopts advanced clever control era, which could understand the automatic bag making method and improve manufacturing efficiency and product great. The DLP-600 water bag/stacking bucket three-dimensional liner bag intelligent bag making machine has multiple useful modules, including automated feeding system, wise manipulate gadget, vacuum suction port, heating sealing tool, and so forth. These modules work collectively to make the bag making method greater green and quicker. The machine's automated feeding device can mechanically feed the roll material into the bag making place, reduce and position it, making sure the accuracy and consistency of each bag size. The shrewd manage gadget can reveal and modify the running status of the gadget to make certain the stableness and reliability of the bag making method. The vacuum suction port module permits the roll material to be tightly attached to the bag making area, heading off the era of bubbles and wrinkles, and ensuring the high-quality of the liner bag. The heating sealing tool can quickly warmth and seal the bag to make sure a decent seal and improve the sealing and leak-proof overall performance of the product. DLP-600 water bag/stacking bucket three-dimensional liner bag intelligent bag making machine has the characteristics of simple operation, strong and dependable, and adjustable bag length. It is suitable for the manufacturing of water baggage and stacked bucket 3-dimensional coated baggage of diverse specifications and sizes.

Product Details

Features：

1. Suitable for all heat sealing materials, including single material pure PE.

2. Bag shape: three-dimensional bag on the valve

3. The system design integrates mechanical, electric and pneumatic, which is a cross-generation automatic bag-making equipment.

4. The system control adopts Panasonic's GM1 programmable controller

5. Recipe making: Different product sizes, bag types and materials form their own production data sets when achieving optimum quality. Unique product recipes: such as heat sealing temperature, film tension, length and number, the horizontal and vertical position of each module, etc., "recipe production" refers to the production based on these data.

6. Pulse heat sealing technology: no preheating required, heating at 150°C/0.85S, cooling at 60°C/1S, more suitable for single material or pure PE bag sealing.

7. Ipad split-screen operation, no matter which position on the machine, you can easily control it.

8. One key to change type: when producing different products, without any mechanical adjustment or product debugging, just one key to switch to complete the product data formula, data storage capacity of up to 10,000 groups.

9. Unwinding system: each roll of film is actively fed by servo motors, with ultrasonic calculation and automatic tension control to ensure that the tension between each layer of film is highly consistent.
